Wall-mounted cantilever crane
WEIHUA CRANE,Wall-mounted cantilever crane (referred to as "wall-mounted crane") is a special machine in the machinery manufacturing and assembly workshop. It can make full use of the space structure of the workshop by using the track arranged on the wall of the multi-layer assembly workshop and walking on the wall, saving the production site and making the operation flexible.According to the main beam structure, the wall walking machine can be divided into two forms: single main beam and double main beam.
- Description
- Specification
WEIHUA CRANE,Wall type cantilever crane description:
Wall-mounted cantilever crane (referred to as "wall-mounted crane") is a special machine in the machinery manufacturing and assembly workshop. It can make full use of the space structure of the workshop by using the track arranged on the wall of the multi-layer assembly workshop and walking on the wall, saving the production site and making the operation flexible.According to the main beam structure, the mural machine is divided into two forms: single main beam (see FIG. 1, FIG. 2) and double main beam (see FIG. 3). The single main beam trolley USES electric hoist, while the double main beam trolley has two forms: traction trolley (see FIG. 3) and standard trolley.The size of running track can be designed according to user requirements.
Environmental conditions:
1. The power supply of the crane is three-phase ac, rated frequency is 50HZ, rated voltage is 380V;
2. The working environment temperature is -20 ~ +45 ℃, and the maximum relative humidity is no more than 85%;
3. The working level of the crane is A3 ~ A5;
5. The working environment of the crane is indoor;
6. Cranes with special requirements for environmental conditions shall be subject to the terms of the order contract.
Ordering instructions:
When ordering or signing the contract, the user must clearly describe the basic parameters of the machine (rated lifting weight, lifting height, span, etc.) in order to provide products that meet the requirements of working conditions and working conditions.
